Toyota Tacoma (2016–2023) dimensions
Generation N300
17′ 8″ (212.3″)539 cm long and 75.2″191 cm wide (Double Cab · 5.0 ft bed). Comes in 3 body styles.
In a standard 2-car garage (20 ft6.1 m × 20 ft6.1 m)
Tight fit
14.5″37 cm to spare lengthwise
Uses the longest trim. Leave about 3 ft0.9 m to walk around the car.
Check your own garageFuel and efficiency
- Powertrains
- Gas
- Combined MPG
- 18–21
Source: EPA fueleconomy.gov
Parking spaces
- Standard (9 ft2.7 m × 18 ft5.5 m)Too long · −9.5″24 cm
- Compact (8 ft2.4 m × 16 ft4.9 m)Too long · −33.5″85 cm
- Parallel (8 ft2.4 m × 22 ft6.7 m)Tight fit · 38.5″98 cm
Typical US sizes; your city’s code may differ.
Toyota Tacoma Double Cab · 5.0 ft bed
| Length | 212.3″539 cm(up to 225.5″573 cm) |
|---|---|
| Width | 75.2″191 cm |
| Height | 70.6″179 cm(up to 71.6″182 cm) |
| Wheelbase | 127.4″324 cm |
| Ground clearance | 9.4″24 cm |
| Seats | 5 |
| Curb weight | 4,425 lb2,007 kg(up to 4,480 lb2,032 kg) |
| Max towing | 6,400 lb2,903 kg(up to 6,700 lb3,039 kg) |
| Max payload | 1,175 lb533 kg(up to 1,505 lb683 kg) |
Based on 71 trims, model years 2016–2020.
Toyota Tacoma Access Cab · 6.1 ft bed
| Length | 212.3″539 cm |
|---|---|
| Width | 74.4″189 cm(up to 75.2″191 cm) |
| Height | 70.6″179 cm |
| Wheelbase | 127.4″324 cm |
| Ground clearance | 9.4″24 cm |
| Seats | 4 |
| Curb weight | 4,305 lb1,953 kg(up to 4,325 lb1,962 kg) |
| Max towing | 3,500 lb1,588 kg(up to 6,800 lb3,084 kg) |
| Max payload | 1,295 lb587 kg(up to 1,620 lb735 kg) |
Based on 58 trims, model years 2016–2020.
Toyota Tacoma Double Cab · 6.1 ft bed
| Length | 225.5″573 cm |
|---|---|
| Width | 75.2″191 cm |
| Height | 70.6″179 cm |
| Wheelbase | 140.6″357 cm |
| Ground clearance | 9.4″24 cm |
| Seats | 5 |
| Curb weight | 4,480 lb2,032 kg |
| Max towing | 6,400 lb2,903 kg(up to 6,600 lb2,994 kg) |
| Max payload | 1,120 lb508 kg(up to 1,370 lb621 kg) |
Based on 27 trims, model years 2016–2020.
Quick answers
- How long is the Tacoma?
- 17′ 8″ (212.3″)539 cm, up to 225.5″573 cm for the longest trim.
- Will the Tacoma fit in a standard 2-car garage?
- Only just: a 20 ft deep garage leaves 14.5″37 cm, not enough to walk around it comfortably. Check your own garage.
- Does it fit a standard parking space?
- Not quite: it overhangs a 9 × 18 ft space by 9.5″24 cm.
- Will it clear a 7 ft garage door?
- Yes. At 71.6″182 cm tall it clears a 7 ft door by 12.4″31 cm (without a roof box).
- How wide is it with mirrors?
- About 84.2″214 cm: 75.2″191 cm body width plus an estimated 9.0″23 cm for the mirrors (manufacturers don't publish it).
How it changed from the previous generation
- Length+4.2″11 cm bigger
- Width+0.6″2 cm bigger
- Height+0.5″1 cm bigger
- Wheelbase about the same
